Pilot-Scale Reactors 10 L – 150 L

H.S. Martin India offers precision-engineered pilot-scale reactors from 10 L to 150 L, designed for process development, scale-up, and pilot production applications. The systems are available in a range of configurations and can be customized to meet specific process, operating, and installation requirements.

10 L – 150 L Vessel volume
10 mbar – 0.5 bar Pressure range
−80°C to +200°C Operating temperature
Enquiry
Pilot scale reactor vessel

Key Features

  • Jacketed vessels — Double-wall configurations available in 10 L, 20 L, 30 L, 50 L, 100 L, and 150 L
  • Vacuum-jacketed vessels — Triple-wall configurations available in 10 L, 20 L, 30 L, and 50 L
  • Zero-hold-up bottom valves — 25 mm flush-bottom valves with fixed or detachable configurations
  • Custom vessel designs — Available with or without baffles
  • Pressure range — Suitable for applications from 10 mbar to 0.5 bar
  • Operating temperature options — −50°C to +180°C and −80°C to +200°C
  • Top flange sizes — DN 200 and DN 300
  • Complete glass assemblies — Supplied with associated glass components, including distillation receivers, as required
  • Skid and support configurations — Stand-alone stands, GMP-oriented models, and up/down systems available to suit installation requirements and project budgets
  • Stirrer drive options — Various motor configurations, including FLP motors with VFD drives
  • Stirring arrangements — Universal stirrer guide, mechanical seal, or magnetic coupling options
  • Stirrer designs — Propeller, PBT, Anchor, and other configurations available according to process requirements
  • Automation options — Fully automated reactor systems can be provided for applications requiring enhanced process control and monitoring

Customized for Scale-Up

Our pilot-scale reactors can be configured to meet specific process volume, temperature, pressure, agitation, glass assembly, skid, and automation requirements. From a stand-alone reactor to a fully integrated automated system, H.S. Martin India provides flexible solutions to support your process development and scale-up needs.

Enquiry

Technical Specification

Vessel Volume
10 L – 150 L
Jacketed Vessel Sizes
10 L / 20 L / 30 L / 50 L / 100 L / 150 L
Vacuum-Jacketed Vessel Sizes
10 L / 20 L / 30 L / 50 L
Bottom Valve
25 mm flush-bottom, zero hold-up volume, fixed or detachable
Vessel Design
Custom designs with or without baffles
Pressure Range
10 mbar – 0.5 bar
Temperature Range
−50°C to +180°C / −80°C to +200°C
Top Flange Size
DN 200 / DN 300
Glass Assembly
Complete glass assembly with associated components, including distillation receivers
Support Configurations
Stand-alone stands / GMP-oriented models / Up-down systems
Stirrer Drive
Various motor configurations, including FLP motors with VFD drives
Stirring Arrangements
Universal stirrer guide / Mechanical seal / Magnetic coupling
Stirrer Designs
Propeller / PBT / Anchor / Other configurations
Automation
Fully automated systems available for enhanced process control and monitoring
